U Bolt – Standard

SKU: UB01 Categories: ,

Standard U Bolts (or Round U Bolts)

Standard U-Bolts are often used for the attaching of pipes or Steel round bars to round Wood or Steel posts, and may even be used to hang wrought Iron pipe in mechanical installations or be embedded in concrete as anchor bolts.

These are essentially a single piece of Mild or Stainless Steel bar that is threaded at the end of either side and then shaped as the letter U.

Standard U Bolts are available from Fastenright in Mild Steel Zinc Plate and Stainless Steel.

U Bolt Dimensions range from M6 to M20 in terms of thread diameter.

Non-standard sizes, materials and finishes are available to order as specials, including small volume manufacture, modifications and custom parts made to drawings.

See all U Bolt types available form Fastenright HERE.

U Bolt Technical Drawing

Technical Data & Available Sizes
Thread Diameter B (mm) C (mm) D (mm)
M6 32 14 13
M6 32 14 16
M6 36 18 16
M6 37 18 14
M6 40 22 18
M6 40 23 16
M6 48 21 30
M6 53 27 30
M6 55 28 27
M6 60 34 30
M6 65 35 30
M8 42 23 16
M8 45 27 25
M8 50 21 30
M8 52 27 25
M8 53 27 25
M8 53 27 30
M8 58 28 25
M8 60 34 25
M8 64 34 30
M8 68 35 32
M8 68 43 25
M8 70 42 40
M8 70 48 28
M8 70 49 28
M8 80 55 35
M8 81 43 41
M8 82 61 28
M8 90 49 46
M8 90 60 40
M8 98 77 28
M8 100 71 40
M8 106 65 35
M8 110 61 53
M8 110 75 40
M8 110 89 28
M8 119 85 40
M8 144 105 40
M10 52 21 30
M10 55 27 30
M10 64 34 32
M10 70 42 40
M10 70 45 40
M10 71 35 34
M10 75 51 40
M10 80 50 40
M10 81 43 41
M10 85 60 40
M10 90 60 40
M10 92 49 45
M10 100 76 40
M10 105 76 40
M10 110 61 53
M10 116 90 40
M10 138 77 70
M10 140 114 40
M10 143 89 70
M10 150 124 40
M10 150 129 40
M10 156 115 55
M10 168 140 40
M10 180 154 40
M10 185 140 70
M10 202 170 40
M10 240 204 40
M10 268 220 60
M12 107 76 40
M12 110 61 53
M12 115 90 40
M12 116 90 40
M12 138 77 70
M12 140 114 40
M12 143 89 70
M12 163 102 75
M12 165 140 40
M12 170 140 40
M12 175 115 75
M12 200 170 50
M12 202 170 40
M12 210 168 70
M12 270 220 60
M12 315 276 40
M14 270 220 60
M14 315 274 60
M16 143 112 50
M16 175 140 50
M16 205 170 55
M16 260 225 50
M16 270 220 60
M16 315 276 50
M16 360 324 50
M16 395 365 75
M16 495 415 85
M16 535 465 85
M16 595 520 85
M20 645 570 90
M20 695 620 90
Size not listed? Please make an enquiry – we may be able to provide it.
